Artículo: AMZ-B07BLKV64Y

Noyito

NOYITO 30A 4 Channel Relay Module High Low Level Trigger with Optocoupler Isolation Load DC 30V AC 250V 30A for PLC Automation Equipment Control, Industrial Control (4-Channel 5V)

Style:

4-Channel 5V

Disponibilidad
En stock
Peso con empaque
0.25 kg
Devolución
Si
Condición
Nuevo
Producto de
Amazon

Sobre este producto
  • Product Applications: PLC automation equipment control, industrial system control, Internet of Things control, electronic enthusiasts to develop experiments, all kinds of circuit modification.
  • Each channel with optocoupler isolation, anti-interference ability.
  • Using high-power relay, control the load up to 30A.
  • Each channel with relay on / off LED indicator.
  • Module load voltage: DC30V / AC 250V 30A ; Module Power Supply : DC 5V(Module supply voltage must be DC, and the voltage to be consistent with the relay voltage.).
  • Manufacturer's One-year After-sale Warranty.
  • NOYITO 30A 1 2 4-Channel Relay Module User Manual https://1drv.ms/b/s!AlzQUCOyZQhKij5iUaqI613FPf1x?e=9gvnH9
₡ 13,989

IMPORT EASILY

By purchasing this product you can deduct VAT with your RUT number

₡ 13,989

Desbloquea Tasa 0 hasta 24 Meses con BAC*

10% OFF en tu primera compra con el código: PRIMERA10

Llega en 5 a 10 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja de USA a tus manos en
Medios de pago Tarjetas de Débito y Crédito

Compra protegida

Disfruta de una experiencia de compra segura y confiable

Conocé más detalles

Electrical parameters: Supply voltage: DC5V; Quiescent current: 5mA; Maximum operating current: 190mA; Trigger mode: High / Low Level Trigger; Load voltage: DC 30V / AC 250V; Load current: 30A; Module life: 10 million times; Switch the maximum frequency: ≤ 5KHz; Product weight: 185g; Size:129x72x22mm (LxWxH); Mounting hole size:126.5x69.5(LxW); Trigger voltage range: High-level trigger: DC 3.3-5V relay on; DC 0-2.5V relay off; ---- Low-level trigger: DC 0-2V relay on; DC 3-5V relay off; Pacakage Included: 1x4-Channel Relay Module
