NOYITO MAX7219 Dot Matrix Module 4 in 1 Display Module Blue Red Green Three Colors with 5Pin Wire Suitable for Microcontroller - Upgrade (Green)
Color:
Green
Disponibilidad
En stock
En stock
Peso con empaque
0.21 kg
0.21 kg
Devolución
Si
Si
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- The MAX7219 is an integrated serial input/output common-cathode display driver that connects a microprocessor to an 8-digit digital 7-segment LED display, or a bar graph display or 64 separate LEDs.
- It includes an on-chip B-type BCD encoder, multi-channel scan loop, segment word driver, and an 8x8 static RAM to store each data. Only one external register is used to set the segment current of each LED.
- A convenient four-wire serial interface can be connected to all common microprocessors. Each data can be addressed without any need to overwrite all displays when updating. The MAX7219 also allows the user to choose whether to encode or not encode each data.
- The entire device includes a 150μA low-power shutdown mode, analog and digital brightness control, a scan limit register that allows the user to display 1-8 bits of data, and a detection mode that allows all LEDs to illuminate.
- There are three colors: red, blue, and green (The blue and green products are upgraded based on user feedback)
₡ 7,486
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
₡ 7,486
Desbloquea Tasa 0 hasta 24 Meses con BAC*
10% OFF en tu primera compra con el código: PRIMERA10
Llega en 10 a 15 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Pagando en Colones ( ₡ )
Visa
Mastercard
American Express
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conocé más detalles
Module parameters: 1. A single module can drive an 8x8 common cathode matrix 2. Module working voltage: 5V 3. Module size: length 12.8 cm X width 3.2 cm X height 1.3 cm 4. With 16 fixing screw holes, aperture 3mm 5. Module with input and output interface, support multiple module cascade 6. Color: red, green, blue Wiring instructions: 1. The left side of the module is the input port, and the right side is the output port. 2. When controlling a single module, you only need to connect the input port to the CPU. 3. When multiple modules are cascaded, the input of the first module is connected to the CPU, the output is connected to the input of the second module, the output of the second module is connected to the input of the third module, and so on. Take 51 MCU as an example: VCC → 5V GND → GND DIN → P2.2 CS → P2.1 CLK → P2.0 Package Included: 1pcs NOYITO MAX7219 Dot Matrix Module 4 in 1 Display Module 1pcs 20cm 5P DuPont line
