JMT USR-TCP232-306 Serial Port RS232/RS485/RS422 to TCP Converter with DHCP and Built-in Webpage with 5V 3A Power Supply (5PCS)
Color:
5PCS
Disponibilidad
En stock
En stock
Peso con empaque
0.83 kg
0.83 kg
Devolución
No
No
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- Ethernet to serial converters USR-TCP232-306 support both interfaces RS232 and RS485, but can only use one at one time. Simple configuration and easy to use.
- Auto-MDI/MDIX, RJ45 port with 10/100Mbps; Work mode: Compatible-with-TCP Server, Compatible-with-TCP Client, UDP Client, UDP Server, HTTPD Client ; Baud rate of serial port can be configured from 600 bps to 230.4 Kbps, supports check bit of none, odd, even, mark and space
- Heartbeat package mechanism to ensure connection is reliable, put an end to dead link; User-defined registration package mechanism, check connection status and use as custom packet header; Under Compatible-with-TCP Server Mode, the connection number with client can be randomly set from 1 to 16, default number is 4.
- IP has been connected can be shown according to connectiong with calculating send / recceive dat. When connection number reaches a maximun, the new connection is kicked off the old one can be configured by user;Parameters can be configured by built-in webpage, AT command, serial port procotol and network procotol. Setting procotol is avaliable to integrate into user?s software.
- Compatible with TCP client short connection function, user-defined the disconnected time.Device restart if no data transmission or timeout. User-defined the restart time. If data buffer needs to clear configuration before Compatible-with-TCP connection establishment;Supports DHCP, automatically obtain an IP address and query IP address via serial setting protocol.The global unique MAC address, user-defined MAC address.
₡ 97,923
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
₡ 97,923
Desbloquea Tasa 0 hasta 24 Meses con BAC*
10% OFF en tu primera compra con el código: PRIMERA10
Llega en 25 o más días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Pagando en Colones ( ₡ )
Visa
Mastercard
American Express
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conocé más detalles
USR-TCP232-306 is a multi serial port ethernet converter,which can realize bi-directional transparent transmission between RS232/RS485/RS422 and Ethernet. User can directly process data interaction through network and device to realize remote data acquisition, remote control and management. Parameters: RS232*1 / RS485*1 / RS422*1 (not use simultaneously) Wide power supply 5-36v DC httpsD client mode, sends serial data in https format Compatible with TCP server/client, UDP server/client,Virtual COMPackage includes Ethernet Port: 10/100Mbps auto switch between cross and direct connection Baud rate: 600-230.4K bps Network Buffer: Send: 6Kbyte, Receive: 4Kbyte COM Buffer: Receive: 2Kbyte Avg. Transmission Delay: Software: Virtual-COM, USR-Cloud, Setup software provided Packing mechanism: 4 bytes of packing time, 400 bytes of packing length DNS function: DNS server addres can be defined Firmware can be upgraded by network Provide Virtual com software Restore factory setting through software or hardware Running across the gateway, switches or routers. Can work in LAN, also can work in the Internet Package includes: 1* Ethernet to serial converter 1* DP9 Female to Female cable 1* 5V1A Power supply
