DEWIN Signal Generator, 4-20mA Generator Adjustable Analog Quantity Current Signal Generator Module
Disponibilidad
En stock
En stock
Peso con empaque
0.20 kg
0.20 kg
Devolución
No
No
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- ✅【Input power】The signal generator can be used for current analog 4-20mA output by manually adjusting the potentiometer to produce 4-20mA current output.
- ✅【Output Current】 The output current can be automatically constant at the set value according to the adjustment, also can be used as a constant current source, its maximum output current does not exceed 20mA.
- ✅【Recommended Current】The input power of the signal generator is DC3.3-30V, and the recommended power supply is 12-24VDC.
- ✅【Support equipment】The module power consumption current is less than 30mA, support general equipment.
- ✅【Applicable range】The general-purpose power supply of the module can be used for PLC, inverter, servo.
₡ 11,435
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
₡ 11,435
Desbloquea Tasa 0 hasta 24 Meses con BAC*
Llega en 15 a 25 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Pagando en Colones ( ₡ )
Visa
Mastercard
American Express
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conocé más detalles
Specifications:Type: Current generatorModel: 4-20mAPotentiometer Installation Hold Diameter: 10mmSize(L*W*H): 73*54*30mm/2.9*2.1*1.2inHole Spacing: 61mm/2.4in Suitable Screws: M3 (NOT included)Weight: 74g(approx.)Wiring:3-32V: DC power supply positiveGND(left): Power supply negative GND(right): 4-20mA output current negative4-20mA-OUT: 4-20mA output current positivePotentiometer: Adjust output range of 4-20mA, clockwise to increase, counterclockwise to reduceInstruction:About Output Impedance Matching:Output signal resistance must meet the following requirementsAccording to the formula:I=U/R(current = voltage/resistance)So the maximum current that signal receiving end can generate is equal to dividing power supply voltage by signal resistance.In this way, current generator still has some resistance.Thus concludes to a formula:Power supply voltage/(signal internal resistance + current generator internal resistance) = output constant currentOur module power supply is 5-32V voltage, so if using low voltage power supply, and the signal internal resistance is large, the output constant current will not be enough.Signal matching requirements is given below:For 24V power supply, signal resistance shall not be greater than 1000 ohms.For 12V power supply, signal resistance shall not be greater than 500 ohms.For 5V power supply, signal resistance shall not be greater than 200 ohms.Note that the power supply voltage cannot be more than 32V.Package Includes:1 x Signal Generator
