Freenove Control Board V5 Rev4 WiFi (Compatible with Arduino IDE), Arm Cortex-M4 Microcontroller, Onboard ESP32-S3, LED Matrix, USB-C Connector, Example Projects and Code Tutorial
Color:
V5 (Rev4) WiFi
Disponibilidad
En stock
En stock
Peso con empaque
0.20 kg
0.20 kg
Devolución
Si
Si
Condición
Nuevo
Nuevo
Producto de
Amazon
Amazon
Sobre este producto
- Latest Version: Upgrade to Arm Cortex-M4 Microcontroller with 48 MHz main core clock speed, 256 KB flash and 32 KB RAM, onboard ESP32-S3 for WiFi and Bluetooth
- Onboard LED Matrix: Bright 12x8 red LED matrix, ideal for creative projects with animations or plotting sensor data, eliminating the need for additional hardware
- Compatibility: Fully compatible with Blue Rev4 WIFI board; some code and libraries may not be compatible with Blue Rev3 board
- Detailed Tutorial: Provides step-by-step guide and several typical projects with code and explanations (The download link can be found on the product box) (No paper tutorial)
- Easy to Use: Just connect the board to your computer (installed IDE and driver) with the USB cable to program it
₡ 14,655
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
₡ 14,655
Desbloquea Tasa 0 hasta 24 Meses con BAC*
10% OFF en tu primera compra con el código: PRIMERA10
Llega en 5 a 10 días hábiles
Con envío
Tienes garantia de entrega
Este producto viaja
de USA ![]()
a tus manos en
![]()
a tus manos en
Compra protegida
Disfruta de una experiencia de compra segura y confiable
![]()
Garantía de entrega
Con Tiendamia todas tus compras cuentan con Garantía de Entrega o devolución total de tu dinero.
Compras 100% seguras y garantizadas, para que pidas lo que sueñas y lo recibas del mundo a tu puerta.
Tarjetas de Débito y Crédito
Pagando en Colones ( ₡ )
Visa
Mastercard
American Express
Pagos a través de PayPal
Compra procesada en dólares con dinero en cuenta o tarjetas internacionales.
PayPal
Conocé más detalles
Purchase Options: V5 WiFi has onboard ESP32-S3 module and 12x8 red LED matrix, V5 Mini does not. This option includes the V5 WiFi board. Overview: This latest upgraded board is armed with a powerful 32-bit microcontroller and an ESP32-S3 for wireless connectivity. Brace yourself for increased processing power, expanded memory, on-board 12x8 LED matrix, and other on-board peripherals. We provide free technical support to help you with any questions and problems. Tutorial and Code: Comes with detailed tutorial and complete code. (Download needed, no paper tutorial.) Including several typical projects with code and explanations. The download link can be found on the product box. Technical Specifications: Microcontroller: Renesas RA4M1 (Arm Cortex-M4) Pins: Digital I/O pins: 14 Analog input pins: 6 DAC: 1 PWM pins: 6 Communication： UART: 1 I2C: 1 SPI: 1 CAN: 1 Power: Circuit operating voltage: 5 V (ESP32-S3 is 3.3 V) Input voltage (VIN): 6-24 V DC current per I/O pin: 8 mA Clock speed: Main core: 48 MHz ESP32-S3: up to 240 MHz Memory: Main core: 256 KB flash, 32 KB RAM, 8 KB EEPROM ESP32-S3: 384 KB ROM, 512 KB SRAM Dimensions: Width: 69 mm Length: 54 mm Package Includes: 1 x Freenove control board V5 (Rev4) WiFi 1 x USB A to C cable
