Artículo: AMZ-B0DL431S82
Teyleten Robot ADXL375 3-Axis High Accuracy Acceleration Sensor Module Replaces ADXL345/346 Module
En stock
0.20 kg
Si
Nuevo
Amazon
- Measurement range up to ±200 g, shock resistance: 10,000 g
- Low power consumption: as low as 35 μA in measurement mode, 0.1 μA in standby mode (VS = 2.5 V)
- 0.1 μA in standby mode (VS = 2.5 V)
- Power consumption automatically scales with bandwidth
- Embedded, 32-stage FIFO buffer minimizes load on processor
- Bandwidth up to 1 kHz
- Bandwidth selectable via serial command
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conocé más detalles
The ADXL375 is a small and thin 3-axis accelerometer with low power consumption and high resolution performance. The digital output data is in 16-bit binary-complement format and is available via SPI (3-wire or 4-wire). The digital output data is in 16-bit binary-complement format and can be accessed via SPI (3-wire or 4-wire) or I2C digital interfaces. The integrated memory management system utilizes a 32-level FIFO buffer that can be used to store data, thereby converting the host computer to the host computer. can be used to store data, thereby minimizing host processor load and reducing minimizes host processor load and reduces overall system power consumption. The low-power mode supports intelligent motion-based power management for threshold sensing at very low power consumption. threshold sensing and motion acceleration measurements with very low power consumption.
