PLC Programmable Controller,24V DC Output, 6 Output Analog Voltage Relay Transistor, 12 bit Analog Input, 8000 Step Logic Operation, for Industrial Control Board, with 8 Input

Conocé más detalles

Spec: Features: Input point X x0-x7, DC24 input, low level valid. X0-5 is the high-speed counting input port (default: 12K,100KHZ optional). Output analog voltage WR3A instruction, corresponding to the value 0-4095. The maximum speed current is 1A. External load common terminating + 24, the other end received the PLC output port Y. Y0-Y5 is optional relay or transistor output, relay output current 5A. The transistor output DC24V, the current maximum 1A. Intermediate relay M: M0-M3071, the power loss preservation range can be set. Specification: Weight: 239g/8.4oz Input point:8 Output point:6 Power supply voltage: DC24V Output current: 5A Analog input: 6AD Analog output: High speed count:6 road 12K optional 100K Pulse output: No Floating point: Support Step motor: No support Memory capacity:8000 step Programming software: GX developer or GX works Program steps: 8000 steps Two communication ports: One RS232 (DB9) serial communication port is FX3u protocol 38400,7, E, 1; One RS485 (485 optional configuration) (communication protocol can be set to D8120). The output point Y : Y0-Y5 is optional relay or transistor output, relay output current 5A. The transistor output DC24V, the current maximum 1A. Y0-1 is high-speed output port (maximum 100K). PWM period is 0-32767US. High The maximum speed current is 1A. External load common terminating + 24, the other end received the PLC output port Y. Analog input: Six-way analog input,12 bit accuracy, input voltage:0-10V,0-20MA; Read the analog quantity with directive. The corresponding values 0-4095. Two-way potentiometer analog input, D8030, D8031. Register D: D0-D7999, power off save range can be set to d0-7999, Indirection pointer V, Z: V0-7, Z0-7 P subroutine number: P0-63 I interrupt: X0-5 external interrupt. Timer
